- For transportation of foodstuffs
- ※No- suitable for transportation of oily foodstuffs or fluid
- Conformed to “Food Sanitary Law, Notification of Ministry of Health , Labour and Welfare No.201” (Except for dissolving test on oils and fats and fatrelated food, Heptanes).
- Excellent in heat-resistance and flexibility
- Can be washed by hot water※1 or 95% ethanol, and keep cleanliness
- Excellent in lightness, flexibility, and abrasionresistance
- Smooth inner and outer surface.
- Translucent wall enables visual check of the material flow.
- ※1.Conditions of Hot Water Washing: Temperature: 80°C or less, Pressure: 0.1MPa or less, Pressurization time: up to 3 minutes.
- For transportation of sake, liquor, soft-drinks, etc
- Additionally, for transportation of other foodstuffs
- For suction and delivery of general usage
- ※Please take a range of 0°C to 50°C as standard allowable temperature, subject to change of allowable pressure depending on use temperature.In case of continuous use, 40°C or less is recommended.
■CAUTIONS
Please avoid the use and storage over the long period of time in the outdoors
| Fluid | Water・hot water、Food、Chemical (including pure water） |
|---|---|
| Material | Non-PVC |
| Temperature | 0 ～ 50 |
| Function | ・Conforms to Ministry of Health,Labour and Welfare Notifications ・Excellent madical durability ・Having transparency (translucent) ・Low odor ・Can be incinerated by fire after use |
| Nominal diameter |
Inside Diameter mm |
Outside Diameter mm |
Pitch mm |
Weight (reference) g/m |
L/coil m |
Allowable pressure (at room temperature) MPa{kgf/cm2｝ |
Allowable bending radius mm |
|---|---|---|---|---|---|---|---|
| 38｛1½｝ | 38.0 | 46.6 | 7.5 | 485 | 50 | 0.30｛2.9｝ | 240 |
| 50｛2｝ | 50.8 | 60.6 | 9.0 | 805 | 0.20｛2.0｝ | 360 |
